0-50KV HIPOT

$120.00 / day

8-14 days : $108.00 / day
15-28 days : $96.00 / day
29-90 days : $84.00 / day
91-180 days : $72.00 / day
181 days+ : $60.00 / day
365 days+ : by agreement. Please contact us.

AC Hipot test set providing continuously adjustable output voltages up to 50kV AC

Available: 2

Categories: , ,

Need assistance? Give us a call or email, we will be happy to help.

All equipment is supplied with a calibration certificate ("if Applicable"), tested & checked before we dispatch it and transported in a heavy duty transport case.

Description

HV50 PFT 503 AC Hipot User Manual

AC Hipot test set providing continuously adjustable output voltages for AC withstand testing of:

  • Switchgear
  • Circuit breakers
  • Reclosers
  • Vacuum bottles
  • Hot sticks
  • Motor windings and Generator Winding
  • Iso phase Busbar
  • Rubber Gloves
  • Other high voltage insulation requiring AC withstand tests

Features:

  • Continuously adjustable output voltage
  • Fixed overload, factory set to 120% of rated output current
  • Zero start and external interlock provision
  • Secondary connected dual-range voltmeter
  • Only single piece, shielded cable output AC hipot rated 50 kVac @ 3 kVA. Half the size and weight of others and easier to use.
  • Three-range current meter with isolated guard/ground return circuit
  • Capacitive load compensation
  • Shielded output cable
  • One-piece portable design
  • Automatic transit protected meters
  • Rugged case with cushion grips
  • Simple controls
Standard Accessories Transport Case, Mains cable, HV output cable, earth cable, Operating manual
Power Supply 230 VAC, 50/60 Hz
Output 0-50 kV AC, 1 kVA resistive load
3 kVA capacitive load
Up to 60 mA current
Output current is reduced at lower voltages
Voltmeter Scaled 0-25/0-50 kV AC, ±2% F.S
Ammeter Scaled 0-1 mA, ±2% F.S. with range multipliers of x1, x10, x100
Duty Cycle 3 kVA: ½ hour ON, 2 hours OFF
2 kVA: 1 hour ON, 1 hour OFF
1 kVA: continuous
Dimensions (instrument) 534mm L x 286mm W x 387 mm H
Weight 34kg

Additional information

Weight 37 kg
Dimensions 54 x 29 x 39 cm
